ECA ® Thermal Insulation Tile
Expanded Clay Aggregate (ECA ®) Roof Top Thermal Insulation Tile
Expanded Clay Aggregate (ECA ®) Roof Top Thermal Insulation Tile is a premium segment of Thermal insulation roof tiles for the heat insulation manufactured with composite materials made from ceramic tile, cement, Fly Ash, and Expanded Clay Aggregates (ECA ®). ECA Roof top thermal insulation tiles are introduced 1st time in India. The product is capable of offering excellent thermal insulation with a temperature difference up to 11°C. (Standard conditions applicable)
Key Features of the product
- Improves the thermal behaviour of the building and saves electricity consumption. Temperature difference up to 11°C.
- High thermal insulation efficiency, which does not change with time. A product with excellent performance for Heat Insulation of Roofs.
- Protects from thermal cycling effects and increases the building life.
- Light in weight and strong.
- Easy application and maintainence free.
Laying
Same as conventional ceramic tile laying technique with 4-5 mm groove between tiles.
P.S. Waterproofing is must before laying the tiles.
Groove Fill
After setting of Expanded Clay Aggregate (ECA ®) Thermal insulation tiles, fill the joints by mixture of fine sand + normal cement mortar or any other cementitious material.
Online video link for reference: Click here to watch the video
SPECIFICATION | ||
---|---|---|
Dimension | 300 mm X 300 mm X 40 mm app. | |
Unit Weight | 3.5 – 4 kgs app. | |
Thermal Conductivity | 0.367 W/m.K (ASTM C-177) | |
Surface Colour | Plain White |
Benefits


Light in Weight
Reduction of 40-50% Load


High Compressive Strength
Cylinder Compressive Strength 0.6 to 3.0 N/mm2


Non-Toxic & Eco- Friendly
Green Material, 100% Eco-Friendly and Sustainable


Excellent Thermal Insulation
Thermal Conductivity 0.097 to 0.10 W/mK


Excellent Sound Insulation
Excellent Acoustic Insulation Property


Excellent Fire Resistance
1 to 6 hrs - 9 to 19 cm LAC 1100 kg/m³


Earthquake Resistant
Lightweight


High Resistance to Water Absorption


Saves Electricity
Excellent insulation properties allows greater energy savings
